Silver Alloy Wires,Electrical Silver Coated Copper Wire, Silver Aluminum Alloy Wire, Sterling Pure Silver Alloy Wires

  • Standard:JB/T 3135-2011,ASTM B298-12
  • Capacity:200km/month
  • Min.Order QTY: 1KM
  • Package: Wooden drum, Steel wooden drum, Coil, Box…
  • Payment Terms: T/T, L/C, D/P
  • Port: Qingdao, Shanghai, Tianjin, Ningbo, Shenzhen
  • Detail
  • Specifications
  • Enquiry

Silver Alloy Wires (Electrical Silver Coated Copper Wire, Silver Aluminum Alloy Wire, Sterling Pure Silver Alloy Wires)meets or exceeds the requirements of all international standards like ASTM,IEC,DIN,BS,AS,CSA,NFC,SS,etc. in addition, we also accept OEM service to meet your special request.

1. standard Silver Coated Copper Wire:
JB/T 3135-2011 Silver coated annealed round copper wire.
ASTM B298-12 Standard Specification for Silver-Coated Soft or Annealed Copper Wire.
Silver Coating: uniform,continous,good adhension.
Surface Finish:The surface of silver coated copper wire is bright,continous and free from harmful defects such as silver grains,burr,mechanical damange.
Joints:One single strand wire each reel. No joints
Advantage:1.High conductivity; 2.High corrosion resistance;
Silver coated copper wire mainly used in High Frequency,wide frequency and high power signal transmission;Microelectronics and superfine electronic wire In these industries such as Electrical wire and cable,electronics,computer,medical treatment,communications,aerospace,military industry, silver coated copper wire  has been used widely.

2.Specification of Ag-Al series Aluminum-Silver alloy wire:
Ag98Al2: 98%silver 2% aluminium
Ag95Al5: 95%silver 5% aluminium
Ag90Al10: 90%silver 10% aluminium
Ag5Al95: 5% sliver 95%aluminium
Ag2Al92: 2% sliver 98%aluminium
Diameter:above 0.5mm
Packing:500g or 1kg per spool.
Features of silver Aluminum alloy wire
Excellent solderability, short wetting time
Uniform distrbution of rosin, good continuity
Low fume, free of odor and harmful valatile gases
Bright and tidy spool
Detailed Product Description
lead free solder wire, no clean solder wire. Our prodct is SGS certificated and passed RoHs.
advantage of silver Aluminum alloy wire
1.Even and bright soldering spot
2.favorable diffusion & welding performance
3.minimum spattering, small smoking & no pungent smell
4.no corrosion
5.lowest and clear flux residue
6.non-conductive, Good insulating properties
Diameter available
0.5mm~5mm (According to customer's requirements)
Application of silver Aluminum alloy wire
silver-aluminium alloy wire can be used for Anticorrosion industry such as the steel structure surface anticorrosion, the container, the bridge, the derrick, the storage tank, the electric power iron tower, Power Tower, the capacitor, metal stent, ductile cast iron pipes,transportation equipment,etc.

3.Pure Silver Alloy Wires, silver winding wire

Material Composition Density g/cm3 Resistivity μΩ. cm Hardness HV kg/mm3
Ag more than99.5 more than10.49 lessthan1.6 30–70

Specification of Pure Silver Wires

Item Name high purity Silver Wires for Coating 99.5% silver Wire
Purity 99.5%;
Shape Wire, According to your request
Available size φ0.025mm-10.0mm Customization is available
Certificates ISO9001:2008, SGS, The third test report
Technics Vacuum Melting, Patented thermo-mechanical process
Application Widely used in coating processing industries
A: Solar Photovoltaic Application.
B: Electronic and Semiconductor Application.
C: Decoration and Coating Application. etc.

Feature of silver alloy wire:

category Pure silver wire
Resistivity Min 1.626
conductivity Min 106
Density 10.53
Tensile strength 170-220
when drawing 1% yield strength 110-150
package detail spool 200mm*250mm*200mm

Our company can supply a variety of silver alloy wires.which made by Pure silver , FAg, AgCdO, AgNi, AgCu, AgSnO2, AgSnO2In2O3, AgZnO, Indium-Tin Alloy Wire, Indium-silver Alloy Wire, Copper-Zinc Alloy Wire, Aluminum-Silver Alloy wire etc.
For now,our silver aluminum alloy wire have been exported to America,South Korea,Russia,Switzerland,France and so on. JYTOP appreciate your kindly feedback,we are looking for establishing business cooperation with you.

JYTOP Cable is a professional Silver Alloy Wires (Electrical Silver Coated Copper Wire, Silver Aluminum Alloy Wire, Sterling Pure Silver Alloy Wires) manufacturer and supplier in China.Our products also include: AAC,AAAC,ACSR,ACAR, Galvanized Steel Wire, Aluminium Clad Steel Wire, PVC wire, PVC/XLPE power cable, Aerial Bundled Cable, rubber cable, control cable, etc. Any Interested, Pls feel free to email us,we will reply to you that day feasible prices and material in time!

Silver Alloy Wires specifications,Silver Alloy Wires types,Silver Alloy Wires names,Silver Alloy Wires table,Silver Alloy Wires sizes,Silver Alloy Wires size chart,Silver Alloy Wires data sheet,Silver Alloy Wires full form
