Fire-resistant Cable,Fire-resistant Flame-retardant Cable

  • Standard:IEC502-1983,IEC331-1970.AS/NZS3013,BS 6387
  • Structure::Cu(Al)/XLPE/CTS(STA)/PVC
  • Min.Order QTY: 300m/reels
  • Package: Wooden drum, Steel wooden drum, Coil, Box…
  • Payment Terms: T/T, L/C, D/P
  • Port: Qingdao, Shanghai, Tianjin, Ningbo, Shenzhen
  • Detail
  • Specifications
  • Enquiry

Fire-resistant Cable (Fire-resistant Flame-retardant Cable)meets or exceeds the requirements of all international standards like ASTM,IEC,DIN,BS,AS,CSA,NFC,SS,etc. in addition, we also accept OEM service to meet your special request.

Application:

Fire resistant flame retardant cable sheaths are design to resist combustion and limit the propagation of flames.it is suitable for power transmission and distribution line with rated voltage 300/500V, 450/750V, 0.6/1kV.Due to relative low cost, fire retardant cables are widely used as fire survival cables.Fire resistant cables are often used to maintain circuit integrity of those vital life safety systems such as fire alarm and suppression services.

Property:

Fire resistant cables are designed to maintain circuit integrity of those vital emergency services during the fire. The individual conductors are wrapped with a layer of fire resisting mica/glass tape which prevents phase to phase and phase to earth contact even after the insulation has been burnt away. The fire resistant cables exhibit same performance even under fire with water spray or mechanical shock situation.

Fire Rated Cables:

1.Flame Retardant – designed for use in fire situations where the spread of flames along a cable route needs to be retarded.
2.Fire Resistant (FR) – cables are designed to maintain circuit integrity of those vital emergency services during the fire.
3.Low Smoke and Fume (LSF) – burns with very little smoke and fumes compared to standard PVC, fumes may contain halogens.
4.Low Smoke Zero Halogen (LSZH) cable – when burns there is very little smoke and fumes (compared to standard PVC the fumes contain no halogens.
5.Alternative names for LSZH – LSZO (Low Smoke Zero Halogen), 0HLS (Zero Halogen Low Smoke), LSHF (Low Smoke Halogen Free).

Construction:

Conductor  Class 1 solid or class 2 stranded copper conductor according to BS EN 60228
Separator  Mica/glass fire barrier tape
Insulation  LSZH (Low Smoke Zero Halogen) or XLPE
Protective Conductor  Tinned copper, full size CPC
Bedding  LSZH (Low Smoke Zero Halogen)
Screen  AL/PET (Aluminum/Polyester Tape)
Armour  SWA (Steel Wire Armor), STA (Steel Tape Armor)
Sheath  LSZH (Low Smoke Zero Halogen) or HOFR (Heat and Oil Resistant and Flame  Retardant) to BS7655 or Heat resistant XLPE
Sheath Color  Red, white, black
Operating Temperature  -25°C to +90°C



JYTOP Cable is a professional Fire-resistant Cable (Fire-resistant Flame-retardant Cable) manufacturer and supplier in China.Our products also include: AAC,AAAC,ACSR,ACAR, Galvanized Steel Wire, Aluminium Clad Steel Wire, PVC wire, PVC/XLPE power cable, Aerial Bundled Cable, rubber cable, control cable, etc. Any Interested, Pls feel free to email us,we will reply to you that day feasible prices and material in time!
